Thumbnail Filmstrip of 5x7 Headlight, High/Low Beam, 9-32 Volts DC, H4 Connector Images
- This DOT Approved Headlight Is Legal For All 5"x7" (146mm) Systems
- Employs Rear Reflective LED Technology
- Low Beam: (1)-15 Watt High Power LED (Lumens: 374)
- High Beam: (4)-3 Watt High Power LED's (Lumens: 968)
- Current (Low Beam): 1.7A@12.8V/0.67A@28V
- Current (High Beam): 2.7A@12.8V/1.08A@28V
- 9-32 Volt DC (Lamp Can Be Used On 12 Volt or 24 Volt Electrical Systems)
- Die Cast Aluminum Black Powder Coated Housing
- UV Protected Polycarbonate Lens
- FMVSS 108 Headlamps: 2B1 DOT Approved
- Standard 3 Pin H4 Connector On a 4-1/2" Wire Pigtail
- Length: 7.87", Height: 5.59", Depth: 4.22"
- Retail Packaging
- Replacement For 6052, 6053, H6054, HP6054
- Cross References: 90951-5, MHL-5X7HILO, 90951, 909515
