Thumbnail Filmstrip of Double Convoluted Air Spring, Replaces Hendrickson Trailer S1159, and Firestone W01-358-7403 Images
- Double Convoluted Air Spring
- Top Plate: 8.98" O.D.
- Top Plate Mounting: (1) Combination Stud/Air Inlet 3/4" O.D. (Male) (16) - 1/4" I.D. (Female) NPT - 1.35" Tall - (1) Threaded Hole - 3/8" (16) - 5.50" Center to Center
- Bottom Plate: 8.98" O.D.
- Bottom Plate Mounting (2) Threaded Holes - 3/8" (16) - 6.21" Center to Center
- Minimum Height: 4.20"
- Internal Bumper: Yes
- Goodyear Bellows Number: 578-92-3-305
- Goodyear Part Number: 2B12-307
- Firestone Bellows Number: 22C
- Firestone Part Number: W01-358-7403
- Replaces: Granning 2725, Hendrickson Trailer S1159, Hendrickson Trailer S2883, Hendrickson Can. B-12514-001, R & S Truck & Body 1040201, Ridewell 1003587403C, Watson & Chalin AS-0007
- Cross References: E2B12307, 2B12307, 4318, 2725, 2B12-307, 64488, FD 330-22 318, FD330-22318, FD33022318, W01-358-7403, W013587403, 554787C1, 12514001, 2B12307, AS0007, 4318, AS4318, AS4318P, 2725, S1159, 578923309, 22, M3507, 3547403, 1426481, 365141, NA1060, B12514001, S2883, SC2021, 200448, 554787C1, 1003587403C, 1040201, 57007403, 352035001, 2B12433, 2B12445, FD 330-22 318, FD33022318
