- Reversible Sleeve Air Spring
- Top Plate: 11.27" O.D.
- Top Plate Mounting: (2) Combination Stud/Air Inlet - 3/4" O.D. (Male) (16) - 1/4" I.D. (Female) NPT - 5.50" Center to Center
- Bottom Piston: 10.13" O.D.
- Bottom Piston Mounting: (1) Stud - 1/2" (13) UNC
- Extended Height: Uninflated - 20.88"
- Collapsed Height: 6.14"
- Internal Bumper: Yes
- Goodyear Bellows Number: 566-28-3-042
- Goodyear Part Number: 1R14-172
- Firestone Bellows Number: 1T19LF-7
- Firestone Part Number: W01-358-8774
- Spring Pro Bellows Number: 888774
- Replaces: Hendrickson Trailer S-25873
- Cross References: 1R14172, 25873, C25873, C-25873, S25873, S-25873, S-27341, S27341, AS-0159G, 65593, 11 10.5F-17 P 745, 1110.5F-17P745, 1110.5F17P745, W01-358-8774, W013588774, 1R14-190, 1R14190, AS-0144, AS0144, 1110.5F, 11105F, AS01591G, 8745, AS8745, 1110.5F, 11105F, 1T19LF7, AS0159, AS01591G, 566283042, 1R14183, 566283044, 11 10.5F-17 P 745, 1110.5F-17P745, 11105F17P745, C01-358-0519, C013580519
