- Cast Iron Steer Axle Hub
- Hub Material: Cast Iron
- Hub Type: Front, 10 Stud, Hub Piloted
- Wheel Stud Bolt Circle: 11.25" (285.75 mm)
- Wheel Studs: Not Included (Use M3668 for both aluminum and steel wheels, See below)
- Brake Type: Drum
- Drum Pilot: 8.78"
- Wheel Stud Standout: N/A
- Hub Cap Bolt Circle: 4.50"
- ABS Ready: Machined for ABS Ring (Ring Not Included)
- Wheel Material: Any
- Inner Bearing Cup: HM212011
- Outer Bearing Cup: 3720
- What's Included: Hub and bearing races
- Cross References: HF803K, HF965, HF965PTP, 106435, M4157, 10018125, 10020111, 105239, 4018402, 90430, CM105239, 15519, 155519, F2HZ1104D, H1002, HF581, HF581K, HF581KX, HF615, HF615K, HF615KX, HF634K, HF671, HF671K, HF687K, HF687KX, HF698, HF698K, HF698KX, HF793K, HF795K, HF802, HF802K, HF803, HF803RA, HF848, HF848K, HF965, HF965K, HUB00137, KIC00100137, 2520, 252313T, 904030020
