SKU: SLP1024 24" Low Profile Amber LED Warning Light Bar With 19 Flash Patterns

• Low Profile Class 1 Amber Warning Light Bar
• Mount Type: Permanent (Includes Option of Bracket or Bolt Mount)
• New V-Cut Optical Design
• 360 Degree Nova Optics
• LED Type: COB (Chip on Board)
• Wattage: 120
• LED Color: Amber
• Lens: Clear Polycarbonate Lens
• Aluminum Base & Cover
• Voltage: 10-30 Volt DC
• Length: 24"
• Width: 8"
• Height: 2-5/8" Tall With Mounting Feet Installed
• 16' 6" Power Cable
• Salt Spray Test Approved
• Vibration Test Approved
• Stainless Steel Mounting Hardware Included
• 19 Selectable Flash Patterns (Momentary Switch Not Included)
1. Single Flash All Lights / SAE Class 1 / CA 13
2. Double Flash All Lights / SAE Class 1
3. Quad Flash All Lights / SAE Class 1
4. Quint Flash All Lights / SAE Class 1
5. Single Flash, All By Day / R65 Class 2, E-MARK
6. Single Flash, All By Night / R65 Class 1, E-MARK
7. Single Flash, Left/Right Alternative
8. Quad Flash, Left/Right Alternative
9. Single Flash, Outside In Alternative
10. Quad Flash, Outside In Alternative
11. Rotation, Slow Mode
12. Rotation, Fast Mode
13. Single, Odd / Even
14. Patrol Mode, Left To Right Then Right To Left
15. Arrow Flash, Left To Right
16. Arrow Flash, Right To Left
17. Airport Mode, Single Flash / ICAO Type C
18. Airport Mode, Single Flash / ICAO Type D
19. Steady On

Certifications

• SAE J845 Class 1 - The Society for Automotive Engineers highest brightness level of SAE Classification in the USA
• SAE J578 Amber - Color Specification for External Lighting Equipment of Motor Vehicles
• IP Rating: IP67 - Complete Protection Against Dust & Waterproof Up to One Meter
• ECE R65 Class 2 - Highest Brightness Level in Europe (both night and day intensity levels)
• ECE R10 - Meets Requirements For Electromagnetic Compatibility, This Light Bar & It's Cable Will Not Effect or Interfere With Any Other Device In Or Surrounding The Vehicle
• ICAO Type C Amber - International Civil Aviation Organization - Meets The Needs of Airport Warning Lights For Optical Angle & Flash Frequency on Mobile Airport Equipment
